Real Project — Build a Production Node.js API

Gorav Singal

April 02, 2026

TL;DR

Build a production API with Express + TypeScript, PostgreSQL (Prisma), Redis caching, JWT authentication, rate limiting, comprehensive testing, Docker containerization, and GitHub Actions CI/CD. This project ties together all concepts from the series.

Real Project — Build a Production Node.js API

What We’re Building

A production-ready Task Management API that demonstrates every concept from this series. This is the kind of API you’d actually ship to production.

Production API Architecture

Tech stack: Express + TypeScript, Prisma + PostgreSQL, Redis, JWT auth, Zod validation, Jest + Supertest, Docker, GitHub Actions.

Project Structure

src/
├── config/
│   ├── database.ts        # Prisma client
│   ├── redis.ts           # Redis client
│   └── env.ts             # Environment validation
├── middleware/
│   ├── auth.ts            # JWT authentication
│   ├── validate.ts        # Zod validation
│   ├── rateLimit.ts       # Redis rate limiter
│   ├── requestId.ts       # Correlation ID
│   └── errorHandler.ts    # Centralized error handling
├── modules/
│   ├── auth/
│   │   ├── auth.controller.ts
│   │   ├── auth.service.ts
│   │   ├── auth.routes.ts
│   │   └── auth.schema.ts
│   └── tasks/
│       ├── tasks.controller.ts
│       ├── tasks.service.ts
│       ├── tasks.routes.ts
│       └── tasks.schema.ts
├── errors/
│   └── index.ts           # Custom error classes
├── utils/
│   └── logger.ts          # Pino logger
├── app.ts                 # Express app setup
└── server.ts              # HTTP server + graceful shutdown

Step 1: Project Setup

mkdir task-api && cd task-api
npm init -y
npm install express @prisma/client ioredis jsonwebtoken bcrypt zod pino helmet cors
npm install -D typescript @types/express @types/node @types/jsonwebtoken @types/bcrypt
npm install -D prisma jest @types/jest ts-jest supertest @types/supertest
npx tsc --init
npx prisma init

Step 2: Database Schema

// prisma/schema.prisma
generator client {
  provider = "prisma-client-js"
}

datasource db {
  provider = "postgresql"
  url      = env("DATABASE_URL")
}

model User {
  id        String   @id @default(uuid())
  name      String   @db.VarChar(100)
  email     String   @unique @db.VarChar(255)
  password  String   @db.VarChar(255)
  role      Role     @default(USER)
  tasks     Task[]
  createdAt DateTime @default(now()) @map("created_at")
  updatedAt DateTime @updatedAt @map("updated_at")

  @@map("users")
}

model Task {
  id          String     @id @default(uuid())
  title       String     @db.VarChar(255)
  description String?
  status      TaskStatus @default(TODO)
  priority    Priority   @default(MEDIUM)
  dueDate     DateTime?  @map("due_date")
  user        User       @relation(fields: [userId], references: [id])
  userId      String     @map("user_id")
  createdAt   DateTime   @default(now()) @map("created_at")
  updatedAt   DateTime   @updatedAt @map("updated_at")

  @@index([userId, status])
  @@index([dueDate])
  @@map("tasks")
}

enum Role {
  USER
  ADMIN
}

enum TaskStatus {
  TODO
  IN_PROGRESS
  DONE
}

enum Priority {
  LOW
  MEDIUM
  HIGH
  URGENT
}

Step 3: Authentication

// src/modules/auth/auth.service.ts
import bcrypt from 'bcrypt';
import jwt from 'jsonwebtoken';
import { prisma } from '../../config/database';
import { redis } from '../../config/redis';
import { AuthenticationError, ConflictError } from '../../errors';

const ACCESS_SECRET = process.env.JWT_ACCESS_SECRET!;
const REFRESH_SECRET = process.env.JWT_REFRESH_SECRET!;

export class AuthService {
  async register(name: string, email: string, password: string) {
    const existing = await prisma.user.findUnique({ where: { email } });
    if (existing) throw new ConflictError('Email already registered');

    const passwordHash = await bcrypt.hash(password, 12);
    const user = await prisma.user.create({
      data: { name, email, password: passwordHash },
      select: { id: true, name: true, email: true, role: true },
    });

    return this.generateTokens(user);
  }

  async login(email: string, password: string) {
    const user = await prisma.user.findUnique({ where: { email } });
    if (!user || !(await bcrypt.compare(password, user.password))) {
      throw new AuthenticationError('Invalid credentials');
    }

    return this.generateTokens({
      id: user.id, name: user.name, email: user.email, role: user.role,
    });
  }

  async refresh(refreshToken: string) {
    const payload = jwt.verify(refreshToken, REFRESH_SECRET) as { sub: string };

    // Check if token is blacklisted
    const isBlacklisted = await redis.get(`blacklist:${refreshToken}`);
    if (isBlacklisted) throw new AuthenticationError('Token revoked');

    const user = await prisma.user.findUnique({
      where: { id: payload.sub },
      select: { id: true, name: true, email: true, role: true },
    });

    if (!user) throw new AuthenticationError('User not found');

    // Blacklist old refresh token
    await redis.set(`blacklist:${refreshToken}`, '1', 'EX', 7 * 24 * 3600);

    return this.generateTokens(user);
  }

  private generateTokens(user: { id: string; name: string; email: string; role: string }) {
    const accessToken = jwt.sign(
      { sub: user.id, role: user.role },
      ACCESS_SECRET,
      { expiresIn: '15m' },
    );
    const refreshToken = jwt.sign(
      { sub: user.id },
      REFRESH_SECRET,
      { expiresIn: '7d' },
    );
    return { user, accessToken, refreshToken };
  }
}

Step 4: Task CRUD with Caching

// src/modules/tasks/tasks.service.ts
import { prisma } from '../../config/database';
import { redis } from '../../config/redis';
import { NotFoundError, ForbiddenError } from '../../errors';
import { TaskStatus, Priority } from '@prisma/client';

export class TasksService {
  async list(userId: string, filters: {
    status?: TaskStatus;
    priority?: Priority;
    page?: number;
    limit?: number;
  }) {
    const { status, priority, page = 1, limit = 20 } = filters;

    const cacheKey = `tasks:${userId}:${status || 'all'}:${priority || 'all'}:${page}`;
    const cached = await redis.get(cacheKey);
    if (cached) return JSON.parse(cached);

    const where = {
      userId,
      ...(status && { status }),
      ...(priority && { priority }),
    };

    const [items, total] = await Promise.all([
      prisma.task.findMany({
        where,
        orderBy: { createdAt: 'desc' },
        skip: (page - 1) * limit,
        take: limit,
      }),
      prisma.task.count({ where }),
    ]);

    const result = { items, total, page, totalPages: Math.ceil(total / limit) };
    await redis.set(cacheKey, JSON.stringify(result), 'EX', 60);

    return result;
  }

  async getById(taskId: string, userId: string) {
    const task = await prisma.task.findUnique({ where: { id: taskId } });
    if (!task) throw new NotFoundError('Task');
    if (task.userId !== userId) throw new ForbiddenError();
    return task;
  }

  async create(userId: string, data: {
    title: string;
    description?: string;
    priority?: Priority;
    dueDate?: Date;
  }) {
    const task = await prisma.task.create({
      data: { ...data, userId },
    });
    await this.invalidateCache(userId);
    return task;
  }

  async update(taskId: string, userId: string, data: Partial<{
    title: string;
    description: string;
    status: TaskStatus;
    priority: Priority;
    dueDate: Date;
  }>) {
    await this.getById(taskId, userId); // Verify ownership
    const task = await prisma.task.update({ where: { id: taskId }, data });
    await this.invalidateCache(userId);
    return task;
  }

  async delete(taskId: string, userId: string) {
    await this.getById(taskId, userId);
    await prisma.task.delete({ where: { id: taskId } });
    await this.invalidateCache(userId);
  }

  private async invalidateCache(userId: string) {
    const keys = await redis.keys(`tasks:${userId}:*`);
    if (keys.length) await redis.del(...keys);
  }
}

Step 5: Request Validation with Zod

// src/modules/tasks/tasks.schema.ts
import { z } from 'zod';

export const createTaskSchema = z.object({
  body: z.object({
    title: z.string().min(1).max(255),
    description: z.string().max(5000).optional(),
    priority: z.enum(['LOW', 'MEDIUM', 'HIGH', 'URGENT']).optional(),
    dueDate: z.string().datetime().optional(),
  }),
});

export const updateTaskSchema = z.object({
  body: z.object({
    title: z.string().min(1).max(255).optional(),
    description: z.string().max(5000).optional(),
    status: z.enum(['TODO', 'IN_PROGRESS', 'DONE']).optional(),
    priority: z.enum(['LOW', 'MEDIUM', 'HIGH', 'URGENT']).optional(),
    dueDate: z.string().datetime().nullable().optional(),
  }),
});

export const listTasksSchema = z.object({
  query: z.object({
    status: z.enum(['TODO', 'IN_PROGRESS', 'DONE']).optional(),
    priority: z.enum(['LOW', 'MEDIUM', 'HIGH', 'URGENT']).optional(),
    page: z.coerce.number().int().positive().default(1),
    limit: z.coerce.number().int().positive().max(100).default(20),
  }),
});

Step 6: Error Handling Middleware

Request Lifecycle

// src/middleware/errorHandler.ts
import { Request, Response, NextFunction } from 'express';
import { AppError } from '../errors';

export function errorHandler(err: Error, req: Request, res: Response, next: NextFunction) {
  if (err instanceof AppError) {
    req.log.warn({ err }, err.message);
    return res.status(err.statusCode).json({
      error: { code: err.code, message: err.message },
      requestId: req.id,
    });
  }

  // Unexpected error
  req.log.error({ err }, 'Unhandled error');
  res.status(500).json({
    error: { code: 'INTERNAL_ERROR', message: 'Something went wrong' },
    requestId: req.id,
  });
}

Step 7: Testing

// __tests__/tasks.integration.test.ts
import request from 'supertest';
import { createApp } from '../src/app';

describe('Tasks API', () => {
  let app: Express.Application;
  let authToken: string;

  beforeAll(async () => {
    app = await createApp();
    const res = await request(app)
      .post('/api/auth/register')
      .send({ name: 'Test', email: '[email protected]', password: 'pass1234' });
    authToken = res.body.accessToken;
  });

  it('POST /api/tasks — creates a task', async () => {
    const res = await request(app)
      .post('/api/tasks')
      .set('Authorization', `Bearer ${authToken}`)
      .send({ title: 'Build API', priority: 'HIGH' })
      .expect(201);

    expect(res.body).toMatchObject({
      title: 'Build API',
      priority: 'HIGH',
      status: 'TODO',
    });
  });

  it('GET /api/tasks — requires authentication', async () => {
    await request(app).get('/api/tasks').expect(401);
  });

  it('GET /api/tasks — returns user tasks', async () => {
    const res = await request(app)
      .get('/api/tasks')
      .set('Authorization', `Bearer ${authToken}`)
      .expect(200);

    expect(res.body.items).toBeInstanceOf(Array);
    expect(res.body).toHaveProperty('total');
  });
});

Step 8: Docker Setup

# Dockerfile
FROM node:20-alpine AS builder
WORKDIR /app
COPY package*.json ./
RUN npm ci
COPY . .
RUN npx prisma generate
RUN npm run build
RUN npm prune --production

FROM node:20-alpine
RUN addgroup -g 1001 app && adduser -u 1001 -G app -s /bin/sh -D app
WORKDIR /app
COPY --from=builder --chown=app:app /app/dist ./dist
COPY --from=builder --chown=app:app /app/node_modules ./node_modules
COPY --from=builder --chown=app:app /app/package.json ./
COPY --from=builder --chown=app:app /app/prisma ./prisma
USER app
EXPOSE 3000
HEALTHCHECK --interval=30s --timeout=5s CMD wget -q --spider http://localhost:3000/health || exit 1
CMD ["sh", "-c", "npx prisma migrate deploy && node dist/server.js"]

Step 9: GitHub Actions CI/CD

name: CI/CD
on:
  push:
    branches: [main]
  pull_request:
    branches: [main]

jobs:
  test:
    runs-on: ubuntu-latest
    services:
      postgres:
        image: postgres:16
        env:
          POSTGRES_DB: test
          POSTGRES_PASSWORD: test
        ports: ['5432:5432']
      redis:
        image: redis:7
        ports: ['6379:6379']
    steps:
      - uses: actions/checkout@v4
      - uses: actions/setup-node@v4
        with: { node-version: 20, cache: npm }
      - run: npm ci
      - run: npm run lint
      - run: npx prisma migrate deploy
        env:
          DATABASE_URL: postgres://postgres:test@localhost:5432/test
      - run: npm test
        env:
          DATABASE_URL: postgres://postgres:test@localhost:5432/test
          REDIS_URL: redis://localhost:6379
          JWT_ACCESS_SECRET: test-secret
          JWT_REFRESH_SECRET: test-refresh

  deploy:
    needs: test
    if: github.ref == 'refs/heads/main'
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4
      - name: Build and deploy
        run: echo "Deploy to ECS (see deploying-nodejs-aws article)"

Production Checklist

  • HTTPS everywhere (TLS termination at load balancer)
  • Rate limiting on auth endpoints (10 req/15min)
  • Request correlation IDs for tracing
  • Structured JSON logging (Pino)
  • Health check endpoint
  • Graceful shutdown handling (SIGTERM)
  • Database connection pooling
  • Redis caching with TTL
  • Input validation on all endpoints (Zod)
  • JWT with refresh token rotation
  • Error responses never expose stack traces
  • Docker multi-stage build (non-root user)
  • CI/CD with automated testing
  • Database migrations in deployment pipeline
  • CloudWatch alerts for 5xx errors and latency

This project ties together every concept from the Node.js Backend Engineering series into a cohesive, production-ready application.

nodejsprojectproductionapifullstackbackend
Share

Related Posts

Error Handling and Logging in Production Node.js

Error Handling and Logging in Production Node.js

Error Handling Strategy Production error handling has two goals: give clients…

WebSockets with Socket.io in Node.js

WebSockets with Socket.io in Node.js

WebSocket vs HTTP Traditional HTTP follows a request/response model — the client…

Testing Node.js — Unit, Integration, and E2E

Testing Node.js — Unit, Integration, and E2E

Testing Strategy A solid testing strategy follows the testing pyramid — many…

Redis — Caching, Sessions, Pub/Sub in Node.js

Redis — Caching, Sessions, Pub/Sub in Node.js

Why Redis for Node.js Redis is an in-memory data store that serves as a cache…

Database Integration — PostgreSQL with Node.js

Database Integration — PostgreSQL with Node.js

Choosing Your PostgreSQL Client Node.js has three main approaches to working…

Performance Optimization and Profiling in Node.js

Performance Optimization and Profiling in Node.js

Profiling First, Optimize Second Never optimize blindly. Always profile to find…

Latest Posts

AI Video Generation in 2025 — Models, Costs, and How to Build a Cost-Effective Pipeline

AI Video Generation in 2025 — Models, Costs, and How to Build a Cost-Effective Pipeline

AI video generation went from “cool demo” to “usable in production” in 2024-202…

AI Models in 2025 — Cost, Capabilities, and Which One to Use

AI Models in 2025 — Cost, Capabilities, and Which One to Use

Choosing the right AI model is one of the most impactful decisions you’ll make…

AI Image Generation in 2025 — Models, Costs, and How to Optimize Spend

AI Image Generation in 2025 — Models, Costs, and How to Optimize Spend

Generating one image with AI costs between $0.002 and $0.12. That might sound…

AI Coding Assistants in 2025 — Every Tool Compared, and Which One to Actually Use

AI Coding Assistants in 2025 — Every Tool Compared, and Which One to Actually Use

Two years ago, AI coding meant one thing: GitHub Copilot autocompleting your…

AI Agents Demystified — It's Just Automation With a Better Brain

AI Agents Demystified — It's Just Automation With a Better Brain

Let’s cut through the noise. If you read Twitter or LinkedIn, you’d think “AI…

Supply Chain Security — Protecting Your Software Pipeline

Supply Chain Security — Protecting Your Software Pipeline

In 2024, a single malicious contributor nearly compromised every Linux system on…
