Introduction
In this post, we will see how to fetch multiple credentials and expose them in environment variable.
Jenkinsfile Stage to Fetch Single Credential
There are many types of credentials that can be stored in Jenkins. The most commonly used is the username/password one.
Lets take an example of a stage, where I need to authenticate against an artifactory server.
stages {
stage('Install requirements') {
steps {
withCredentials([[
$class: 'UsernamePasswordMultiBinding',
credentialsId: 'MY_API_KEY',
usernameVariable: 'ARTIFACTORY_USERNAME',
passwordVariable: 'ARTIFACTORY_PASSWORD']
]) {
sh """
python3.8 -m pip install virtualenv
python3.8 -m venv python_env
source python_env/bin/activate
python3.8 -m pip install --upgrade pip
python3.8 -m pip install -r requirements.txt -i https://${ARTIFACTORY_USERNAME}:${ARTIFACTORY_PASSWORD}@artifactory.myorg.com/artifactory/api/pypi/pypi-myorg-release/simple
deactivate
"""
}
}
}
}In above Jenkinsfile, I’m reading credentials from a stored credential in Jenkin with id MY_API_KEY and exposing the username in variable: ARTIFACTORY_USERNAME, and password in variable: ARTIFACTORY_PASSWORD
Jenkinsfile Stage to Fetch Multiple Credentials
There are many cases, where I need to read more than one credentials,
stage('Run deployer') {
steps {
echo 'Deploying Artifacts to k8s Env...'
withCredentials([
[$class: 'UsernamePasswordMultiBinding',
credentialsId:"AZURE_SERVICE_SECRET",
usernameVariable: 'AZURE_SERVICE_USERNAME',
passwordVariable: 'AZURE_SERVICE_SECRET'],
[$class: 'UsernamePasswordMultiBinding', credentialsId:"MY_API_KEY",
usernameVariable: 'ARTIFACTORY_USERNAME',
passwordVariable: 'ARTIFACTORY_PASSWORD']
]) {
sh """
sudo curl -LO "https://dl.k8s.io/release/v1.25.2/bin/linux/amd64/kubectl"
sudo install -o root -g root -m 0755 kubectl /usr/local/bin/kubectl
kubectl version --client
echo "deploy to env=${params.DeployEnv}, artifact=${params.ArtifactId}, version=${params.Version}"
echo "Preparing runtime env..."
python3.8 -m pip install virtualenv
python3.8 -m venv python_env
source python_env/bin/activate
python3.8 -m pip install --upgrade pip
python3.8 -m pip install -r requirements.txt -i https://${ARTIFACTORY_USERNAME}:${ARTIFACTORY_PASSWORD}@artifactory.myorg.com/artifactory/api/pypi/pypi-myorg-release/simple
echo "Ready to run deployment..."
python3.8 deploy.py "${params.DeployEnv}" "${params.ArtifactId}" "${params.Version}" "./ethos_deployment"
deactivate
"""
}
}
}The syntax is the same, it is just that I’ve used multiple credentials id and usage will be the same.
